DTCam

Python module for capturing images from pre-determined addresses

This utility focuses on capturing images from a weathercam provided by Road DigiTraffic based on its station location.

Road DigiTraffic provides data about public cameras from their weathercam stations, which includes information about its region name. Therefore, we can filter stations by their region name and find specific stations in a certain region (e.g., Helsinki, Porvoo, …).

Camera address book

First, we can build an address book of camera installed address, and image capture url from Road DigiTraffic. The format of this address book can be a list of JSON-formatted data objects:

[
    {
        "address": <camera installed location>,
        "url": <capture image url>,
    },
    {
        "address": <camera installed location>,
        "url": <capture image url>,
    },
    ....
]

---

source

build_address_book

 build_address_book (stations_url:str)

---

source

address_book

 address_book (stations_url:str='https://tie.digitraffic.fi/api/weathercam
               /v1/stations', force_update=False)

Get an address book [{“address”:, “url”:}]

---

source

camera_address_book

 camera_address_book (stations_url:Optional[str]='https://tie.digitraffic.
                      fi/api/weathercam/v1/stations',
                      update:Optional[bool]=False)

Get weather camera location addressbook of camera location:image url. You can get an capture of camera from this url

	Type	Default	Details
stations_url	Optional	https://tie.digitraffic.fi/api/weathercam/v1/stations	Weather Camera URL
update	Optional	False	Update addressbook forcely
Returns	str		List of "camera location":"image url"

Example address book from Road DigiTraffic:

addresses = camera_address_book()
json.loads(addresses)[0]

{'address': 'Porvoo,Tie 7 Porvoo, Harabacka,Porvoo,Uusimaa',
 'url': 'https://weathercam.digitraffic.fi/C0150200.jpg'}

Weathercam image capturing

Based on possible weathercam stations, we extract images from these cameras by requesting the corresponding URL:

---

source

stations

 stations (key:str)

“Get all weather station including key word

Example with finding stations in Porvoo:

Porvoos = stations("Porvoo")
Porvoos[0]

{'type': 'Feature',
 'id': 'C01502',
 'geometry': {'type': 'Point', 'coordinates': [25.616391, 60.390238, 0.0]},
 'properties': {'id': 'C01502',
  'name': 'vt7_Porvoo_Harabacka',
  'collectionStatus': 'GATHERING',
  'state': None,
  'dataUpdatedTime': '2024-12-12T03:26:57Z',
  'presets': [{'id': 'C0150200', 'inCollection': True}]}}

For DigiTraffic, the image from a weather camera can be retrieved with a weathercam URL using the presets data:

---

source

presets

 presets (station:dict)

Get all presets at a given weather station

preset = presets(Porvoos[0])[0]
imageUrl = preset['imageUrl']
imageUrl

'https://weathercam.digitraffic.fi/C0150200.jpg'

Download and save this image to local disk:

---

source

capture

 capture (preset:dict)

Capture image at a given preset location in a Weather station, and return an image path

hdr, path = capture(preset)
hdr

{'Content-Type': 'image/jpeg', 'Content-Length': '66682', 'Connection': 'keep-alive', 'x-amz-id-2': 'e1nXLX4h6A1+r45u0fdlv7R44L3NqThwbK0/xJ7cUHnPUzkR6z4GhW5s0HhjppQttrBA0mLj+DoGPEfuI5ARaQ==', 'x-amz-request-id': '7YJ7D76VBEJA18S2', 'last-modified': 'Thu, 12 Dec 2024 13:03:04 GMT', 'x-amz-expiration': 'expiry-date="Sat, 14 Dec 2024 00:00:00 GMT", rule-id="Delete versions and current images after 24h"', 'x-amz-server-side-encryption': 'AES256', 'X-Amz-Meta-Last-Modified': 'Thu, 12 Dec 2024 13:03:04 GMT', 'x-amz-version-id': 'MbujShinwFlbCASbDJ4XE957WpwwBYT4', 'Accept-Ranges': 'bytes', 'Server': 'AmazonS3', 'Date': 'Thu, 12 Dec 2024 13:10:19 GMT', 'ETag': '"1c38821750ddec3363436dcd1077eb83"', 'Vary': 'Accept-Encoding', 'X-Cache': 'Hit from cloudfront', 'Via': '1.1 95ad0c949c0fe7e97075c6690b8574aa.cloudfront.net (CloudFront)', 'X-Amz-Cf-Pop': 'HEL51-P1', 'Alt-Svc': 'h3=":443"; ma=86400', 'X-Amz-Cf-Id': 'p4oSYL7h9m8R9Xua8kSJe59PlJJuqITUAx_V5e9urJ3GJSoAzOEu_w==', 'Age': '54'}

display(Image.open(path))

We can all previous utilities and implement a function that capture images based on location keyword:

---

source

cap

 cap (key:str='Porvoo')

Capture an image at specified location, save it, and return its path

	Type	Default	Details
key	str	Porvoo	Location keyword
Returns	str		Image path

Test capturing an image of Porvoo:

path = cap("Porvoo")
display(Image.open(path))

Simulated GPT workflow

This section tests integrating with our current GPT framework. This function can be used in combination with previous functions in the vision module:

from llmcam.core.fc import *
from llmcam.core.fn_to_schema import function_schema
from llmcam.vision.ytlive import capture_youtube_live_frame
from llmcam.vision.gpt4v import ask_gpt4v_about_image_file
from llmcam.vision.yolo import detect_objects

tools = [
    function_schema(capture_youtube_live_frame, "Youtube Live Capture"),
    function_schema(ask_gpt4v_about_image_file, "GPT4 Vision"),
    function_schema(detect_objects, "YOLO Object Detection"),
    function_schema(camera_address_book, "Weather Camera Address Book"),
    function_schema(cap, "Weather Station Capture")
]
messages = form_msgs([
    ("system", "You are a helpful system administrator. Use the supplied tools to assist the user."),
    ("user", "Name some locations to capture weather station images from the default address book."),
])
complete(messages, tools=tools)
print_msgs(messages)

>> System:
You are a helpful system administrator. Use the supplied tools to assist the user.
>> User:
Name some locations to capture weather station images from the default address book.
>> Assistant:
Here are some locations from the default weather camera address book where you can capture images:
1. Porvoo, Uusimaa - [Link](https://weathercam.digitraffic.fi/C0150200.jpg) 2. Inkoo, Uusimaa -
[Link](https://weathercam.digitraffic.fi/C0150301.jpg) 3. Hanko, Uusimaa -
[Link](https://weathercam.digitraffic.fi/C0150302.jpg) 4. Karkkila, Uusimaa -
[Link](https://weathercam.digitraffic.fi/C0150401.jpg) 5. Helsinki, Uusimaa -
[Link](https://weathercam.digitraffic.fi/C0150402.jpg) 6. Lohja, Uusimaa -
[Link](https://weathercam.digitraffic.fi/C0150601.jpg) 7. Hanko, Uusimaa -
[Link](https://weathercam.digitraffic.fi/C0150701.jpg) 8. Mäntsälä, Uusimaa -
[Link](https://weathercam.digitraffic.fi/C0150801.jpg) 9. Hyvinkää, Uusimaa -
[Link](https://weathercam.digitraffic.fi/C0150901.jpg) 10. Vantaa, Uusimaa -
[Link](https://weathercam.digitraffic.fi/C0153201.jpg)  These links provide current weather images
from various locations across Finland.

# Continue the conversation and ask the user about the image
messages.append(form_msg("user", "Capture a weather station image from Helsinki and tell me some basic information about it."))
complete(messages, tools=tools)
print_msgs(messages)

>> System:
You are a helpful system administrator. Use the supplied tools to assist the user.
>> User:
Name some locations to capture weather station images from the default address book.
>> Assistant:
Here are some locations from the default weather camera address book where you can capture images:
1. Porvoo, Uusimaa - [Link](https://weathercam.digitraffic.fi/C0150200.jpg) 2. Inkoo, Uusimaa -
[Link](https://weathercam.digitraffic.fi/C0150301.jpg) 3. Hanko, Uusimaa -
[Link](https://weathercam.digitraffic.fi/C0150302.jpg) 4. Karkkila, Uusimaa -
[Link](https://weathercam.digitraffic.fi/C0150401.jpg) 5. Helsinki, Uusimaa -
[Link](https://weathercam.digitraffic.fi/C0150402.jpg) 6. Lohja, Uusimaa -
[Link](https://weathercam.digitraffic.fi/C0150601.jpg) 7. Hanko, Uusimaa -
[Link](https://weathercam.digitraffic.fi/C0150701.jpg) 8. Mäntsälä, Uusimaa -
[Link](https://weathercam.digitraffic.fi/C0150801.jpg) 9. Hyvinkää, Uusimaa -
[Link](https://weathercam.digitraffic.fi/C0150901.jpg) 10. Vantaa, Uusimaa -
[Link](https://weathercam.digitraffic.fi/C0153201.jpg)  These links provide current weather images
from various locations across Finland.
>> User:
Capture a weather station image from Helsinki and tell me some basic information about it.
>> Assistant:
I captured an image from a weather station in Helsinki at the location "Tie 101 Helsinki, Pakila,"
specifically at Kehä 1 Itään. Here are some basic details about the image:  - **Dimensions:** 1280 x
720 - **Time of Day:** Afternoon - **Visibility:** Clear - **Sky Light Conditions:** Daylight -
**Number of Cars:** 10 - **Street Lights:** 5 - **Buildings:** No buildings visible - **Artificial
Lighting:** Minimal - **Waterbodies Visible:** No  The image shows a well-lit area with clear
visibility, and there are no people, trucks, boats, or available parking spaces visible.

# Continue the conversation and detect objects in the image
messages.append(form_msg("user", "Can you detect what objects are captured in this image?"))
complete(messages, tools=tools)
print_msgs(messages)

image 1/1 /home/nghivo/tinyMLaaS/llmcam/data/cap_2024.12.12_13:06:53_Kehä 1 Itään_C0151301.jpg: 384x640 7 cars, 54.9ms
Speed: 5.5ms preprocess, 54.9ms inference, 221.6ms postprocess per image at shape (1, 3, 384, 640)
>> System:
You are a helpful system administrator. Use the supplied tools to assist the user.
>> User:
Name some locations to capture weather station images from the default address book.
>> Assistant:
Here are some locations from the default weather camera address book where you can capture images:
1. Porvoo, Uusimaa - [Link](https://weathercam.digitraffic.fi/C0150200.jpg) 2. Inkoo, Uusimaa -
[Link](https://weathercam.digitraffic.fi/C0150301.jpg) 3. Hanko, Uusimaa -
[Link](https://weathercam.digitraffic.fi/C0150302.jpg) 4. Karkkila, Uusimaa -
[Link](https://weathercam.digitraffic.fi/C0150401.jpg) 5. Helsinki, Uusimaa -
[Link](https://weathercam.digitraffic.fi/C0150402.jpg) 6. Lohja, Uusimaa -
[Link](https://weathercam.digitraffic.fi/C0150601.jpg) 7. Hanko, Uusimaa -
[Link](https://weathercam.digitraffic.fi/C0150701.jpg) 8. Mäntsälä, Uusimaa -
[Link](https://weathercam.digitraffic.fi/C0150801.jpg) 9. Hyvinkää, Uusimaa -
[Link](https://weathercam.digitraffic.fi/C0150901.jpg) 10. Vantaa, Uusimaa -
[Link](https://weathercam.digitraffic.fi/C0153201.jpg)  These links provide current weather images
from various locations across Finland.
>> User:
Capture a weather station image from Helsinki and tell me some basic information about it.
>> Assistant:
I captured an image from a weather station in Helsinki at the location "Tie 101 Helsinki, Pakila,"
specifically at Kehä 1 Itään. Here are some basic details about the image:  - **Dimensions:** 1280 x
720 - **Time of Day:** Afternoon - **Visibility:** Clear - **Sky Light Conditions:** Daylight -
**Number of Cars:** 10 - **Street Lights:** 5 - **Buildings:** No buildings visible - **Artificial
Lighting:** Minimal - **Waterbodies Visible:** No  The image shows a well-lit area with clear
visibility, and there are no people, trucks, boats, or available parking spaces visible.
>> User:
Can you detect what objects are captured in this image?
>> Assistant:
The image captured at Helsinki's weather station contains 7 cars. No other objects were detected in
the image.
